Ultrafide U4PRE Pre-Amplifier
Ultrafide U4PRE Pre-Amplifier
Ultrafide U4PRE Pre-Amplifier
Ultrafide U4PRE Pre-Amplifier

Ultrafide U4PRE Pre-Amplifier

£4,500.00
/
Tax included. Shipping calculated at checkout.
  • UK Wide Shipping Available
  • Long established Official Retailer
  • Usually in stock and dispatched in 1-5 working days

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

  • Quad outputs available for use simultaneously, to allow signal distribution for multi-amping of loudspeakers
  • Class A circuits, minimum signal path, simplicity at its core
  • DC (and Super Low Frequency) Coupled Systems
  • Over engineered toroidal power supply
  • Highly configurable ultra premium phono stage – Suitable for use with a wide range of moving magnet and moving coil cartridge
  • Ultra premium, super powerful dsicreet class A/B headphone amplifier
  • OLED screen & Remote control for volume, balance, source select, mute, and standby etc
  • Expansion port for additional future interfaces (carries dc power and signal)
Audio Channels (quantity) 2 Left & Right
Audio Inputs 10 6 RCA (Single Ended)
4 XLR (Balanced)
Input Impedance RCA 47k
Input Impedance XLR 10k
Input RFI Filtering Capacitance RCA 100pF XLR 500pF
Additional Phono Loads (adjustable) 7 steps 80R/500R 7 steps 150pF/470pF
Audio Outputs 10 4 RCA (Single Ended)
4 XLR (Balanced)
2 on ¼ inch H/Phone Jack
Output Impedance Line 75R Headphones 200mR
Maximum Output Line 2.5Vrms Headphones 7Vrms (1.5W)
Voltage Gain Line nominal 0dB
H/Phono nominal +10dB
Phono nominal +35dB to +71dB in 3dB steps
Volume Control Range -95dB to +10dB 1dB steps +-0.05dB
Sensitivity Line 316mV nominal (2.4v max)
Phono (1KHz) 0.16mV to 5 mV for 316mV
Dynamic Range (line) 115dB Un-Weighted 22-22KHz
Phono Johnson Noise Hi gan 0R source EIN-146dBu
Distrotion 0.003%
Power Supply Connector 6A IEC
Fuse 1A
Nominal Power Supply Voltage 115Vac (60Hz) or 230Vac (50Hz)
Power Isolation Switch On Rear Panel
Standby Switch On Front Panel
Remote Standby 2 x Out Connectors on Rear Panel
Power Indicator Green indicates out of standby Red indicates fault
Power consumption Operational 20W Standby 1W
Product size / weight (packed) 590(L) x 405(W) x 152(H)mm 14.65kg (GROSS)
Product size / weight (unpacked) 382(L) x 325(W) x 97(H)mm 13.05kg (NET)
