Product Summary
The Audio-Technica AT-VM740xML is a premium dual moving magnet phono cartridge from the VMx Series, designed for listeners looking to extract greater detail, clarity and spatial information from their vinyl collection. Combining Audio-Technica’s dual-magnet VM generator with a nude Microlinear stylus, the AT-VM740xML delivers highly accurate groove tracing together with an expansive, precisely defined stereo image.
Audio-Technica’s VM design uses two magnets positioned to correspond with the left and right channels of the stereo record groove. This arrangement closely mirrors the geometry of the cutter head used during record production, helping provide excellent channel separation and extended frequency response.
The AT-VM740xML features a nude Microlinear stylus designed to trace even very fine groove modulations with exceptional accuracy. Its advanced profile provides a more precise contact with the groove than conventional conical or elliptical designs, helping reveal subtle musical detail while maintaining excellent tracking performance.
The stylus is mounted to a tapered aluminium-pipe cantilever. By reducing mass towards the stylus tip, the tapered design allows the cantilever to respond rapidly to groove movements, improving transient response and helping the cartridge reproduce music with greater immediacy and definition.
Inside the cartridge, Audio-Technica uses paratoroidal coil construction with two coils per channel. This improves generating efficiency, while a centre shield plate positioned between the left and right channels helps reduce crosstalk and preserve a clear, stable stereo image.
The VMx generation also introduces PCUHD - Pure Copper Ultra High Drawability - wire for the cartridge coils. Audio-Technica has reduced the number of coil turns compared with previous designs, helping lower electrical mass and improve transient response while retaining the tonal richness and natural presentation expected from a high-quality moving-magnet cartridge.
The generator is housed within a substantial die-cast aluminium body designed to suppress unwanted vibration and resonance. Threaded mounting inserts are built directly into the cartridge body, allowing installation with just two screws and making setup particularly convenient on tonearms with integrated headshells.
With a 3.2mV output and standard 47kΩ recommended loading, the AT-VM740xML is compatible with conventional moving-magnet phono stages. Its removable stylus assembly also allows straightforward replacement and provides compatibility with most alternative AT-VMx Series styli, giving owners the option to experiment with different stylus profiles in the future.
Key Benefits
- Premium Audio-Technica VMx Series dual moving magnet cartridge
- Nude Microlinear stylus for highly accurate groove tracing
- Microlinear profile retrieves fine musical and spatial detail
- Tapered aluminium-pipe cantilever reduces mass near the stylus tip
- Dual-magnet VM generator mirrors the geometry of a stereo cutter head
- Paratoroidal coil construction uses two coils per channel for improved generating efficiency
- PCUHD Pure Copper Ultra High Drawability coil wire
- Reduced coil turns improve transient response
- Centre shield plate reduces crosstalk between left and right channels
- Die-cast aluminium housing helps suppress unwanted vibration and resonance
- Threaded cartridge-body inserts simplify installation
- 20Hz - 25kHz frequency response
- 25dB channel separation at 1kHz
- 3.2mV output suits standard moving-magnet phono stages
- Recommended tracking force of 2.0g
- Replaceable stylus design
- Replacement stylus: AT-VMN40xML
- Compatible with most alternative AT-VMx Series replacement styli
- Compatible with standard 1/2-inch cartridge mounting systems
- V-cut stylus protector helps identify stylus position when cueing a record
Technical Specifications
Cartridge Design
- Type: VM Dual Moving Magnet
- Series: Audio-Technica VMx Series
- Housing: Die-cast aluminium
- Mounting: Standard 1/2-inch cartridge mount
- Threaded Mounting Holes: M2.6 x 2
- Weight: 8.8g
Stylus & Cantilever
- Stylus Construction: Nude Microlinear
- Stylus Curvature Radius: 2.2 x 0.12 mil
- Cantilever: Tapered aluminium pipe
- Vertical Tracking Angle: 20°
- Replacement Stylus: AT-VMN40xML
Tracking & Compliance
- Tracking Force Range: 1.8g - 2.2g
- Standard / Recommended Tracking Force: 2.0g
- Static Compliance: 20 x 10⁻⁶ cm/dyne
- Dynamic Compliance: 7 x 10⁻⁶ cm/dyne at 100Hz
Audio Performance
- Frequency Response: 20Hz - 25kHz
- Channel Separation: 25dB at 1kHz
- Output Balance: 1.0dB at 1kHz
- Output Voltage: 3.2mV at 1kHz, 5cm/sec
Electrical Specifications
- Recommended Load Impedance: 47kΩ
- Recommended Load Capacitance: 150 - 250pF
- Coil Impedance: 3.2kΩ at 1kHz
- DC Resistance: 750Ω
- Coil Inductance: 480mH at 1kHz
- Coil Wire: PCUHD Pure Copper Ultra High Drawability
Dimensions
- Height: 29.0mm
- Width: 18.3mm
- Depth: 17.5mm
- Weight: 8.8g
Stylus Compatibility
- Standard Replacement Stylus: AT-VMN40xML
- Compatible with most AT-VMx Series replacement styli
- Alternative VMx stylus profiles can be fitted for different playback characteristics
- Mono VMx stylus models are excluded from cross-compatibility
What’s in the Box
- 1 x Audio-Technica AT-VM740xML cartridge with AT-VMN40xML stylus
- 2 x M2.6 10mm cartridge installation screws
- 2 x M2.6 8mm cartridge installation screws
- 2 x M2.6 5mm cartridge installation screws
- 2 x Washers
- 1 x Non-magnetic screwdriver
- 1 x Stylus brush
