Product Summary
The Dynavector XX-2A is a high-performance low-output moving coil cartridge combining a highly refined vibration system with Dynavector's specially annealed magnetic circuit. Developed to deliver excellent resolution, wide dynamics and a spacious, natural presentation, it builds on the acclaimed XX-2 design with significant improvements to the magnetic assembly.
An Alnico magnet works alongside Dynavector's patented Flux Damper technology to stabilise magnetic flux during playback, while the rigid magnetic structure is carefully assembled and individually adjusted. A 6mm solid boron cantilever and PF line-contact stylus provide low moving mass and highly accurate groove tracing.
With an output of 0.28mV and a recommended load impedance above 30 ohms, the XX-2A is designed for use with a quality moving coil phono stage or suitable step-up transformer. Its 8.9g body weight and moderate compliance make it compatible with a wide range of quality tonearms.
Key Benefits
- High-performance low-output moving coil cartridge
- Specially annealed magnetic circuit
- Alnico magnet system
- Dynavector Flux Damper technology
- High-rigidity magnetic structure
- 6mm solid boron cantilever
- PF line-contact stylus
- Excellent 30dB channel separation
- Low 6-ohm internal impedance
- 0.28mV output
- Compatible with a wide range of quality tonearms
- Threaded mounting holes for straightforward installation
- Hand assembled and individually adjusted in Japan
Technical Specifications
Cartridge
- Type: Low-Output Moving Coil
- Magnetic System: Alnico Magnet with Flux Damper
- Output Voltage: 0.28mV at 1kHz, 5cm/sec
- Frequency Response: 20Hz - 20kHz ±1dB
- Channel Separation: 30dB at 1kHz
- Channel Balance: 1.0dB at 1kHz
- Compliance: 10mm/N
- Internal Impedance: 6 ohms
- Recommended Load Impedance: Greater than 30 ohms
Stylus & Cantilever
- Stylus Type: PF Line Contact
- Stylus Radius: 7 x 30 microns
- Cantilever: 6mm Solid Boron
- Tracking Force Range: 1.8 - 2.2g
- Recommended Tracking Force: Approximately 2.0g
Mounting
- Cartridge Weight: 8.9g
- Mounting Screws: M2.5
- Threaded Cartridge Body
- Suitable for a Wide Range of Light to Medium-Mass Tonearms
Phono Stage Matching
- Requires a Moving Coil Phono Stage or Suitable Step-Up Transformer
- Recommended Load: Greater than 30 ohms
- 47k ohm MC phono inputs may also be used where appropriate
What's in the Box
- 1 x Dynavector XX-2A Moving Coil Cartridge
- Mounting Screws
- Stylus Guard
- Documentation
